Hikvision DS-1271ZJ-140-DM45 plafondbeugel voor dome-camera's, aluminiumlegering, wit

For installers who need a rock-solid ceiling anchor without the bulk, the DS-1271ZJ-140-DM45 delivers a low-profile 45 mm drop that keeps dome cameras tight to the surface. Its 140 mm aluminum alloy plate spreads the load evenly, and the integrated cable hole routes wiring cleanly through the center — no side-entry gaps, no exposed loops.

Highlights

• Aluminum alloy construction with spray-painted Hik White finish resists corrosion indoors and out
• Supports up to 4.5 kg, covering a wide range of Hikvision dome cameras
• 45 mm height minimizes the visual footprint while leaving room for connectors
• Integrated cable management hole keeps installations tidy and tamper-resistant
• Operating range from -40°C to 60°C and 0–90% non-condensing humidity

In daily use

Mount the plate to any flat ceiling surface, pull the camera's pigtail through the central opening, and secure the dome with the included hardware. Because the bracket is only 45 mm tall, it works well in corridors, lobbies, and covered outdoor areas where a pendant mount would be too obtrusive. The aluminum alloy body dissipates heat effectively and won't warp or crack in freezing temperatures, while the white powder coating blends with standard ceiling tiles.

Full specifications

• Type: Ceiling mount bracket
• Material: Aluminum alloy
• Diameter: 140 mm
• Height: 45 mm
• Max load capacity: 4.5 kg
• Colour: Hik White
• Surface treatment: Spray painting
• Mounting surface: Flat ceiling
• Cable management: Integrated cable hole
• Operating temperature: -40°C to 60°C
• Operating humidity: 0% to 90% RH (non-condensing)
• Corrosion resistance: Yes
• Compatible with: Select Hikvision dome cameras

Final note

Pair this bracket with any Hikvision dome that uses a 140 mm base pattern for a secure, professional installation that lasts for years.
