TP-Link VIGI C430 turret IP-beveiligingscamera binnen & buiten 2304 x 1296 pixel plafond

VIGI 3MP Full-Color Turret Network Camera delivers clear, colorful 24-hour monitoring using a large-aperture lens, high-sensitivity sensor and built-in supplemental lights to capture details even in very low light. The camera supports AI-based human and vehicle classification, multiple smart detection types, an integrated microphone for audio capture, and several video enhancement technologies to preserve important details.

Advantages

The camera provides full-color night monitoring at up to 3MP resolution while using Smart IR, WDR and 3D DNR to improve image clarity. Built-in AI enables accurate identification of humans and vehicles and reduces false alarms. PoE simplifies installation by transmitting power and data over a single RJ45 cable. Multiple management options (web UI, NVR UI, VIGI app and VIGI Security Manager) allow flexible control of the surveillance system.

Key specifications

• Image sensor and lens: large-aperture lens with high-sensitivity sensor supporting up to 3MP resolution
• Color night vision: built-in supplemental lights for full-color monitoring in low light
• AI capabilities: human and vehicle classification and configurable alarm rules
• Smart detection: boundary crossing, intrusion area, tampering detection, object removal/abandonment
• Audio: built-in microphone with approximately 15 ft (≈4.5 m) pickup range
• Video enhancement: Smart IR, WDR, 3D DNR and Night Vision
• Compression and storage: efficient video compression to reduce bandwidth and disk usage
• Power and connectivity: Power over Ethernet (PoE) via RJ45
• Management: web UI, NVR UI, VIGI app, VIGI Security Manager
• Installation: turret form factor with side outlet and ceiling routing options

How to use

Connect the camera to your network and power using a single RJ45 cable supporting PoE, mount the turret on the desired surface or route the cable through a dropped ceiling or the camera’s side outlet for neat installation. Configure detection zones and alarm rules via the web UI, NVR UI, VIGI app or VIGI Security Manager. Adjust image settings and enable SmartVid enhancements as needed to balance clarity and storage consumption. Review recorded video and audio when events are triggered by the configured smart detections.

Recommendations

For reliable results, position the camera to minimize direct glare and obstructions, configure human and vehicle classification to match your environment, and ensure the PoE switch or injector provides sufficient power. Regularly check firmware updates and verify recording settings to maintain optimal performance.
