HPE Aruba Networking AP-755 (RW) 5-pack

The HPE Aruba Networking AP-755 (RW) 5-Pack is a high-performance indoor access point solution designed for enterprise wireless networks. This pack includes five AP-755 access points, each delivering dual-band Wi-Fi 5 (802.11ac) with 4x4:4 MIMO technology, providing aggregate throughput of up to 2.3 Gbps. Ideal for high-density environments such as offices, schools, and hospitals, these access points support both controller-managed and Aruba Instant (IAP) modes for flexible deployment.

Advantages

With integrated omni-directional antennas and support for 802.3at PoE+, the AP-755 offers easy installation and reliable connectivity. The 4x4:4 spatial streams on both 2.4 GHz and 5 GHz bands ensure robust performance for demanding applications. Security features include WPA2, WPA3 (via software update), and 802.1X authentication, making it suitable for sensitive environments.

Suitable for

• Enterprise offices and campus networks
• Educational institutions and lecture halls
• Healthcare facilities and hospitals
• Retail and hospitality venues
• Any high-density indoor wireless deployment

Key specifications

• Wi-Fi Standard: IEEE 802.11a/b/g/n/ac (Wi-Fi 5)
• Frequency Bands: Dual-band (2.4 GHz and 5 GHz)
• MIMO Configuration: 4x4:4 SS (4 spatial streams) per band
• Max Data Rate: 1.733 Gbps (5 GHz) + 600 Mbps (2.4 GHz)
• Aggregate Throughput: Up to 2.3 Gbps
• Ethernet Ports: 2 x 10/100/1000BASE-T Gigabit Ethernet
• Power over Ethernet: 802.3at PoE+
• Antenna Type: Integrated omni-directional
• Management Modes: Controller-managed or Aruba Instant AP
• Power Consumption: Max 25.5W
• Security: WPA2, WPA3 (via software update), 802.1X, VPN
• Mounting: Ceiling tile rail, wall mount
• Operating Temperature: 0°C to 50°C (32°F to 122°F)
• Form Factor: Indoor, plenum-rated
• Quantity per Pack: 5

Recommendations

For optimal performance, pair with an Aruba controller or use in Instant mode. Ensure PoE+ switch or injector is available. Ideal for upgrading existing Wi-Fi 5 networks or building new high-capacity wireless infrastructure.
