METZ CONNECT 110175 vermogensrelais 24 V DC 1 wisselcontact 16 A zwart

Switching up to 16 A at 250 V AC, the METZ CONNECT 110175 power relay delivers reliable control in a compact PCB-mount package. Its 24 V DC coil and silver nickel contacts are built for long-term endurance.

Overview

The METZ CONNECT 110175 is a power relay with a single changeover contact (SPDT). It is designed for PCB mounting and features a coil voltage of 24 V DC. The relay can switch loads up to 16 A and 250 V AC / 30 V DC. The contact material is silver nickel (AgNi), ensuring good conductivity and resistance to wear. The coil power consumption is 0.5 W, and the coil resistance is 1152 Ohm. The relay is black in color.

What stands out

• High switching capacity: 16 A at 250 V AC
• Low coil power consumption: 0.5 W
• Durable silver nickel contacts
• Wide operating temperature range: -40 to +85 °C
• Flux-proof construction (RT II)

Technical details

• Contact configuration: 1 changeover (SPDT)
• Coil voltage: 24 V DC
• Max. switching current: 16 A
• Max. switching voltage: 250 V AC / 30 V DC
• Contact material: Silver nickel (AgNi)
• Coil power consumption: 0.5 W
• Coil resistance: 1152 Ohm
• Insulation voltage (coil/contact): 4000 V AC
• Dielectric strength (contact/contact): 1000 V AC
• Operating temperature range: -40 to +85 °C
• Mounting type: PCB mount
• Number of pins: 5
• Electrical life (rated load): 100,000 operations
• Mechanical life: 10,000,000 operations
• Protection degree: RT II (flux proof)
• Approvals: VDE, UL, CSA, CE

Our verdict

A robust and efficient power relay for industrial and commercial applications, offering high switching capacity and long service life in a compact form factor.
