SHIELD R-BOX 300R 9S 9U wandbehuizing kast zwart 600x460x300 mm

The SHIELD R-BOX 300R 9S is a robust 9U wall mount rack cabinet designed for secure and organized installation of 19-inch network and IT equipment. With a compact depth of 300 mm, it is ideal for space-constrained environments such as server rooms, offices, and industrial settings. The cabinet is constructed from cold rolled steel with a black powder-coated finish (RAL 9005) and features a tempered glass front door with a key lock for equipment visibility and security.

Advantages

This wall mount rack offers a perfect balance of capacity and space efficiency. The 9U height accommodates standard 19-inch equipment while the 300 mm depth fits shallow devices like switches, patch panels, and small servers. The tempered glass door allows easy monitoring of LED indicators without opening the cabinet. Removable side panels provide convenient access for cabling and maintenance. The cabinet is pre-assembled and includes mounting hardware for quick installation.

Suitable for

• Network switches and routers
• Patch panels and cable management
• Small servers and UPS units
• Audio/video equipment
• Industrial control systems

Key specifications

• Rack type: Wall mount
• Rack capacity: 9U
• Rack width: 19 inch
• External dimensions (WxHxD): 600 x 460 x 300 mm
• Material: Cold rolled steel
• Door: Tempered glass front door with key lock
• Side panels: Removable
• Cable entry: Top and bottom with knockouts
• Ventilation: Passive, fan ready
• Max load capacity: 60 kg
• Colour: Black (RAL 9005)
• Finish: Powder coated
• Assembly: Fully assembled
• Protection rating: IP20
• Mounting hardware included: Yes

Recommendations

For optimal cable management, use the top and bottom cable entry points with brush strips or grommets. Ensure the wall mounting surface can support the total weight of the cabinet and installed equipment. For environments requiring higher protection, consider additional ventilation or fan kits.
