TELEGÄRTNER L82005A0000 10 m LC-duplex naar LC-duplex OM3 multimode glasvezel patchkabel, aqua, LSZH 100017385

High-speed data links in data centers and enterprise networks demand low-loss, reliable fiber optic connectivity. The TELEGÄRTNER L82005A0000 patch cable delivers OM3 multimode performance with LC-Duplex connectors on both ends, ensuring dependable 10 Gigabit Ethernet transmission over short to medium distances.

Who is it for

Network engineers, data center technicians, and IT professionals who need a robust, ready-to-use fiber patch cable for patching between panels, switches, and transceivers. It suits installations requiring LSZH jacketing for improved fire safety in enclosed spaces.

Main features

• 10 m length with LC-Duplex to LC-Duplex connectors
• OM3 multimode fiber (50/125 µm) optimized for 850 nm VCSEL systems
• Aqua LSZH jacket for low smoke and zero halogen emission
• Operating temperature range from -40 to 85 °C
• Insertion loss below 0.3 dB and return loss above 30 dB

Specifications

• Connector type: LC-Duplex to LC-Duplex
• Fiber type: OM3 multimode
• Cable configuration: Duplex (zipcord)
• Core/cladding diameter: 50/125 µm
• Attenuation: 2.5 dB/km at 850 nm, 0.8 dB/km at 1300 nm
• Bandwidth (OFL): 1500 MHz·km at 850 nm, 500 MHz·km at 1300 nm
• Jacket material: LSZH
• Operating/storage temperature: -40 to 85 °C

Tips

Pair with OM3-compatible transceivers for optimal performance. The duplex zipcord design allows easy polarity reversal if needed.
