Vaddio Middle Atlantic BRK12 - rack - zwart - 12U - 48,3 cm (19 inch)

Wall mount rack cabinet with a solid steel, lockable door and 12U of 19-inch rack space, engineered for secure AV, IT, and security equipment installation in space-constrained environments.

Advantages

The BRK12 delivers robust equipment protection in a compact form factor. Its welded steel construction and black powder coat finish ensure durability, while the reversible, lockable door safeguards critical hardware. Removable vented side panels promote passive airflow, and top, bottom, and rear knockouts simplify cable routing. With a 150 lb (68 kg) weight capacity, it accommodates a wide range of rack-mount devices.

Suitable for

• AV integrators mounting codecs, amplifiers, or matrix switchers in classrooms and conference rooms.
• IT administrators deploying network switches, patch panels, and servers in small offices or retail back rooms.
• Security professionals housing NVRs and PoE injectors in utility closets or restricted areas.
• Any application requiring a lockable, wall-mounted enclosure with 12U of rack space.

Key specifications

• Rack capacity: 12U
• Rack width: 19 inches (48.3 cm)
• Usable depth: 18 inches (45.72 cm)
• Overall dimensions (H x W x D): 24.5 x 21.1 x 18 inches (62.23 x 53.59 x 45.72 cm)
• Weight capacity: 150 lbs (68 kg)
• Material: Welded steel with black powder coat finish
• Door: Solid steel, reversible, lockable
• Side panels: Removable, vented
• Cable management: Top, bottom, and rear knockouts
• Ventilation: Passive, with provisions for optional fans
• Compliance: RoHS, UL Listed

Recommendations

For installations where floor space is limited but equipment security is paramount, the BRK12 offers an ideal balance of capacity, strength, and accessibility. Pair with optional fan kits for active cooling in high-density setups.
