Vivolink Meeting Room Package Large (BYOD-LARGE) 4K60 4:4:4 samenwerkingssysteem met 100m verlenging

Experience uncompromised 4K@60Hz 4:4:4 video quality across distances up to 100 metres. The Vivolink Meeting Room Package Large (BYOD-LARGE) delivers a complete, professional-grade collaboration system for large meeting rooms, conference rooms, and classrooms, combining seamless BYOD connectivity, powerful USB-C power delivery, and intuitive control in one integrated solution.

Overview

Built around the VLBYOD-100 switcher, this package provides two HDMI inputs and one USB-C input with automatic and manual switching, ensuring effortless presentation transitions. A single HDMI output feeds the room display, while embedded HDMI audio simplifies cabling. The included VLEXTUSB30 and VLEXTHDMI100 extenders transmit USB 3.0 and HDMI signals up to 100 metres over CatX cable, preserving full 4K60 4:4:4 resolution and high-speed data integrity. The VLUSBCHUB USB-C hub adds Ethernet connectivity and up to 100W power delivery, enabling a single-cable connection for laptops and mobile devices. The VLPANEL8 programmable control panel offers eight buttons for customised room control, with additional RS-232 and IP control options for integration with third-party systems.

What stands out

• True 4K@60Hz 4:4:4 video with HDCP 2.2 compliance for crystal-clear, colour-accurate presentations.
• 100-metre extension for both HDMI and USB 3.0 over CatX, ideal for large spaces.
• USB-C input with up to 100W power delivery charges laptops while transmitting video and data.
• Automatic input switching plus manual override for flexible meeting flow.
• KVM functionality allows control of connected computers from the meeting room.
• 8-button programmable control panel simplifies room operation.

Technical details

• Video inputs: 2x HDMI, 1x USB-C (with Power Delivery up to 100W)
• Video output: 1x HDMI
• Maximum resolution: 4K@60Hz (4:4:4)
• HDCP compliance: HDCP 2.2
• USB connectivity: USB 3.0 host and device ports, KVM support
• Ethernet: LAN pass-through on switcher, Ethernet port on USB-C hub
• Audio: Embedded HDMI audio
• Control: VLPANEL8 (8 programmable buttons), RS-232, IP control
• Extension distance: Up to 100m for HDMI and USB 3.0 over CatX
• Included components: VLBYOD-100 switcher, VLUSBCHUB USB-C hub, VLEXTUSB30 USB extender, VLEXTHDMI100 HDMI extender, VLPANEL8 control panel

Our verdict

The Vivolink BYOD-LARGE package eliminates the complexity of large-room AV integration. With long-distance 4K60 4:4:4 extension, comprehensive USB-C connectivity, and flexible control, it is a future-proof foundation for any modern collaboration space.
