BCS-PAN-P10-N buitenpaneelstation voor 2-draads intercom – 2MP camera, 125° groothoek, IP65, IK07, zilver/grijs

An outdoor panel station engineered for BCS 2-wire video intercom systems, the BCS-PAN-P10-N delivers crisp 1080p video with a 125° wide-angle lens to capture visitors from head to toe. Its rugged aluminum alloy front and IP65/IK07 ratings ensure reliable operation in harsh weather and against vandalism, while two-way audio with echo cancellation makes conversations clear even in noisy environments. A backlit nameplate and single call button provide a clean, user-friendly interface for single-family homes.

Advantages

The panel’s 2MP CMOS sensor and IR LED illumination guarantee sharp images day and night, with a 125° horizontal field of view reducing blind spots at the entrance. Built-in microphone and speaker with echo cancellation enable natural, hands-free communication. The relay output (NO/NC) allows direct control of an electric door strike or gate opener, simplifying installation without extra modules. Powered directly from the BCS line (DC 24V), it requires no separate power supply, and the surface-mount design fits standard flush or wall boxes.

Suitable for

• Single-family homes and apartments using BCS 2-wire intercom monitors
• Entrances requiring a vandal-resistant, weatherproof door station
• Installations where clear two-way audio and wide-angle video are essential
• Users needing remote door release via relay output

Key specifications

• Camera: 1/2.8" CMOS, 2MP (1080p), 2.0mm lens, 125° horizontal / 75° vertical viewing angle
• Night vision: IR LED illumination for low-light conditions
• Audio: Two-way with built-in microphone and speaker, echo cancellation
• Door unlock: 1x relay output (NO/NC)
• Connectivity: BCS 2-wire line system
• Protection: IP65 dust/water resistant, IK07 vandal resistant
• Material: Aluminum alloy front panel, silver/grey finish
• Power: DC 24V from BCS line
• Operating temperature: -30°C to +60°C
• Call buttons: 1 (single-family), backlit nameplate
• Installation: Surface mount

Recommendations

For optimal performance, pair the BCS-PAN-P10-N with a compatible BCS 2-wire video monitor and use a dedicated 24V power supply if the line length exceeds 50 meters. Ensure the mounting surface is flat and clean, and seal cable entry points to maintain the IP65 rating. Test the relay output with your door strike before final installation.
