Cimco 187707 dubbele adereindhuls 1,5 mm² deels geïsoleerd zwart 100 stuks

The Cimco 187707 twin ferrule handles two conductors in a single crimp, a practical alternative to using separate single ferrules when wiring dense terminal blocks. Its black partially insulated sleeve leaves the crimp zone visible for inspection while still providing a touch-safe grip.

Highlights

• Twin ferrule for two 1.5 mm² conductors
• Partially insulated, black sleeve
• Tin-plated electrolytic copper
• Funnel-shaped wire entry for easy insertion
• Pack of 100 pieces

In daily use

The funnel-shaped entry guides both conductors into the barrel without strand folding. The partial insulation keeps the crimp area accessible for a reliable connection and allows visual verification after crimping. With a sleeve length of 8 mm and total length of 14 mm, it fits standard terminal blocks and complies with DIN 46228 Part 4.

Full specifications

• Nominal cross-section: 1.5 mm²
• Ferrule type: Twin
• Insulation: Partially insulated, black
• Conductor material: Electrolytic copper, tin-plated
• Sleeve length (L1): 8 mm
• Total length (L3): 14 mm
• Number of conductors: 2
• Wire entry: Funnel-shaped
• Temperature resistance: -40 °C to +105 °C
• Max. voltage rating: 600 V
• Standard: DIN 46228 Part 4
• Packaging quantity: 100 pieces

Final note

A reliable twin ferrule for professional wiring tasks where two conductors must be terminated together.
