DSIT CAT5e U/UTP netwerk-installatiekabel met massieve ader, 100 m, grijs

For installers who need a dependable, full-spool backbone without the premium of shielded cable, the DSIT CAT5e U/UTP 100-meter grey reel delivers clean Gigabit performance in a straightforward PVC jacket. Unlike patch leads that are pre-terminated and limited to short runs, this solid-conductor cable is built for permanent indoor runs—from patch panels to wall outlets or long horizontal stretches—where a 24 AWG copper core keeps attenuation low and signal integrity high across the entire 100 MHz bandwidth.

Highlights

• CAT5e performance: supports 1000BASE-T Gigabit Ethernet and 100 MHz bandwidth
• U/UTP construction: unshielded twisted pairs for standard indoor environments with low EMI
• Solid bare copper conductors: 24 AWG, ideal for punch-down terminations and fixed installations
• 100-meter reel: continuous length for multiple drops or a single long run
• Grey PVC jacket: durable, flexible, and easy to identify in structured cabling
• Compliant with TIA/EIA-568-B.2 for reliable interoperability

In daily use

Pull the cable from the reel, cut to length, and terminate with standard RJ45 keystone jacks or patch panels—the solid conductors seat firmly in IDC terminals and stay put. The grey jacket is marked at regular intervals for accurate measuring, and the PVC material resists abrasion during installation. With an outer diameter of about 5.0 mm, it fits easily into trunking, conduits, and cable trays. Operating temperature from -20°C to 60°C covers most indoor and sheltered outdoor applications.

Full specifications

• Product Type: Network Installation Cable
• Cable Category: CAT5e
• Shielding Type: U/UTP (Unshielded / Unfoiled Twisted Pair)
• Conductor Type: Solid
• Wire Gauge: 24 AWG
• Number of Conductors: 8 (4 twisted pairs)
• Conductor Material: Copper
• Cable Length: 100 meters
• Colour: Grey
• Jacket Material: PVC (Polyvinyl Chloride)
• Max Data Transfer Rate: 1000 Mbps (1 Gigabit Ethernet)
• Max Bandwidth: 100 MHz
• Application Environment: Indoor Installation
• Standard Compliance: TIA/EIA-568-B.2
• Packaging: Cable Reel
• Outer Diameter: ~5.0 mm
• Operating Temperature: -20°C to 60°C
• Storage Temperature: -20°C to 75°C

Final note

With its solid copper core and generous 100-meter length, this reel is a practical choice for structured cabling projects that demand consistent performance without unnecessary shielding.
