ESPE LNF-3024 LED-schakelvoeding 24V 30W 1,25A IP20

The ESPE LNF-3024 is a high-quality LED switching power supply designed for indoor LED lighting applications. It provides a constant voltage output of 24V DC with a maximum power of 30W and a current of 1.25A. This power supply is ideal for powering LED strips, modules, and other low-voltage LED fixtures.

Advantages

Reliable and efficient power conversion with overload and short circuit protection ensures safe operation. Compact plastic housing with natural air convection cooling allows for silent and maintenance-free performance. Screw terminals provide secure and easy connection.

Suitable for

• Indoor LED lighting systems
• LED strips and modules
• Signage and decorative lighting
• Low-voltage DC applications

Key specifications

• Product Type: LED Switching Power Supply
• Output Voltage: 24V DC
• Output Power: 30W
• Output Current: 1.25A
• Input Voltage: 100-240V AC
• Input Frequency: 50/60 Hz
• IP Rating: IP20
• Cooling: Natural Air Convection
• Housing Material: Plastic
• Connection: Screw Terminals
• Operating Temperature: -10°C to +50°C

Recommendations

For optimal performance, ensure the total load does not exceed 30W. Use appropriate gauge wire for connections. This power supply is not dimmable and is intended for indoor use only.
