64-kanaals IP NVR BCS-P-NVR6408-A-4K(4) 8 SATA 4K HDMI

The BCS-P-NVR6408-A-4K(4) is a high-performance 64-channel network video recorder designed for professional surveillance systems. It supports up to 12 MP resolution recording and offers 8 SATA bays for extensive storage. With dual Gigabit Ethernet ports and 384 Mbps bandwidth, it ensures smooth video transmission. Ideal for large-scale installations requiring reliable 24/7 monitoring.

Advantages

Supports 64 IP cameras with 12 MP resolution; 8 HDD bays (up to 10 TB each) for massive storage; H.265+ compression saves bandwidth and storage; Dual HDMI outputs for 4K display; 16-channel simultaneous playback for efficient review.

Suitable for

• Large commercial or industrial surveillance systems
• Retail chains, warehouses, and campuses
• Government and public safety installations
• Any environment requiring high-channel count and high-resolution recording

Key specifications

• 64 IP channels, max 12 MP recording
• 8 SATA HDD bays, up to 10 TB each
• H.265+/H.265/H.264+/H.264 compression
• 2x Gigabit Ethernet, 384 Mbps bandwidth
• 2x HDMI (4K), 1x VGA output
• 16-channel simultaneous playback
• 16 alarm inputs, 4 alarm outputs
• Audio I/O: 1 RCA in, 1 RCA out
• USB: 2x USB 2.0, 1x USB 3.0
• 2U rack-mountable, embedded Linux

Recommendations

For optimal performance, use with BCS PoE switches and high-capacity WD Purple or Seagate SkyHawk HDDs. Ensure proper ventilation in the rack cabinet.
