BCS BCS-TA18FWR4L4 8MP HD analoge turretcamera, 3,6mm, 40m IR, IP67

The BCS BCS-TA18FWR4L4 is a high-performance 8 Megapixel HD analog turret camera designed for professional surveillance. Featuring a 1/2.7" CMOS sensor, it delivers crisp 3840x2160 resolution. With switchable video output (HDCVI/AHD/HDTVI/CVBS), it integrates seamlessly into existing analog systems. The fixed 3.6mm lens provides an 87° horizontal field of view, while 40m Smart IR ensures clear night vision. Its IP67-rated metal housing withstands harsh outdoor conditions, and DWDR, 3D DNR, BLC/HLC enhance image quality in challenging lighting.

Advantages

True 8MP resolution for detailed identification; versatile video output compatibility; robust IP67 metal construction for outdoor durability; Smart IR for balanced night illumination; advanced image processing (DWDR, 3D DNR) for clear footage in high-contrast scenes.

Suitable for

• Outdoor perimeter surveillance
• Parking lots and entrances
• Retail and commercial premises
• Warehouses and industrial sites
• Residential outdoor monitoring

Key specifications

• Image Sensor: 1/2.7" CMOS
• Max Resolution: 8 MP (3840x2160)
• Video Output: HDCVI / AHD / HDTVI / CVBS (switchable)
• Lens: Fixed 3.6mm, 87° H. FOV
• IR Distance: 40m (Smart IR)
• Min. Illumination: 0.005 Lux (Color), 0 Lux (IR on)
• Day/Night: Mechanical IR cut filter
• WDR: DWDR
• Noise Reduction: 2D/3D DNR
• BLC / HLC: Yes
• OSD Menu: Yes (Coax Control)
• Power: DC 12V, max 5.3W
• Operating Temperature: -40°C to +60°C
• Ingress Protection: IP67
• Housing Material: Metal

Recommendations

For optimal performance, use a quality DC 12V power supply and compatible HD analog DVR. Ensure proper cable connections for coax control. Ideal for upgrading existing analog systems to 8MP without replacing cabling.
